Complete Lowering Drop Kit | 4 Inch Narrowed | Drum Spindles | 1969-1977 Classic VW Type 1 Beetle Ghia

⭐️⭐️⭐️⭐️⭐️ - "Lower your VW the right way—this complete kit provides every part you need, engineered for stance, handling, and confidence only Airkewld delivers." - ⭐️⭐️⭐️⭐️⭐️

The best way to lower a 1969–1977 Classic Volkswagen Beetle or Karmann Ghia is with a Complete PRObuilt Lowering Kit from Airkewld. This bolt-on solution lets you dial in the perfect stance—2.5" to 10" of drop in the front and stock height to 6" of drop in the rear—while maintaining safety, strength, and precision.

Remember, stock height is relative. Even if your suspension hasn’t been altered, torsion bars sag with time, giving your VW a lower-than-original look. Fresh out of the showroom, a Beetle had a 6" fender-to-tire gap up front and a touch of positive camber in the rear. This kit restores full adjustability while giving you the flexibility to set your ride exactly where you want it.

Products Included in This Kit

• 4" Ultimate Adjustable Narrowed Beam

• New Torsions

• Tie Rods with Premium Tie Rod Ends

• Steering Dampener

• Beam Bolts, Rubber Body Pads, Inspection Plate & Seal

• PRObuilt Arms with Premium Ball Joints (pre-installed & broken in)

• Drop Drum Spindles (BAD Series Brake compatible)

• Sport Front & Rear Shocks

• Lowered Eccentrics

The Ultimate Beam (UB)

The heart of the kit is the Ultimate Beam, giving you up to 7.5" of smooth up-and-down movement. Built with Delrin bushings, grease zerks, and a steering dampener bracket, the UB is available in stock width or narrowed up to 4".

What’s included with the UB?

• Satin black powder coat

• Installed adjusters & Delrin bushings

• Hardware (dampener lock nut & washer)

What’s recommended?

4" narrowed beams are the most popular choice, giving you clearance for wider wheels, drop spindles, and disc brakes that add track width.

Drop Drum Spindles

• Lowers your VW 2.5"

• Works with stock drum brakes or BAD Series Disc Brakes

• Bolt-on ready with OE fit

PRObuilt Arms

Each PRObuilt Arm Set undergoes a complete audit, rebuild, and upgrade process:

• OEM arms stripped, blasted, checked for straightness

• Powder coated for long-term durability

• Premium ball joints pressed in with custom fixtures

• Ball joints broken in to ensure smooth, effortless steering

Kewl Features

• Assembled in the USA by the PRO’s

• Powder coated finish

• Bolt-on ready

• Quality checked for safety & performance

Kewl Features of the Complete Kit

• American-made components

• 7.5" of ride height adjustability

• Adjust in 1/16" increments

• No body mods required—bolt-on installation

• Industry’s best packaging for safe delivery

FAQ

Do I need to cut the body to install this kit?
No. The beam’s inside dimension is 29 13/16", leaving 1/16" of clearance on each side.

How can a 4" narrowed beam fit if there’s only 1/2" clearance per side?
We rework the tube ends and gusset outward, giving the proper spacing.

Will your BAD Series Brakes fit?
Yes. GEN 1 & GEN 2 BAD Series Brakes fit all DRUM Drop Spindles in this kit.

Are the PRObuilt Arms rebuilt originals?
Yes, OEM arms are audited, straightened, powder coated, and fitted with premium ball joints. They may show “history marks,” but all meet strict QC standards.

Do you need my old arms?
Not required, but we’re always looking for good cores. Check out our core collective marketplace here.

✅ No body mods. All bolt-on. All PRO.
