Swing Axle Air Ride Bracket Kit | 1949-1968 Classic VW Type 1 Beetle Ghia

⭐️⭐️⭐️⭐️⭐️ - "Designed for Classic VW swing axle models, this rear air ride bracket kit delivers the strength, geometry, and reliability required for a proper air suspension setup." - ⭐️⭐️⭐️⭐️⭐️

Convert your Classic VW to rear air ride with Airkewld’s Swing Axle Air Ride Bracket Kit. Designed as a replacement component for our air ride systems, this kit includes the critical brackets, heim joints, hardware, and fittings needed to integrate air suspension on swing axle applications.

⚠️ Note: This kit is sold as a replacement part for Airkewld air ride systems. No instructions are included, and we cannot provide tech support for installation on non-Airkewld applications.

What’s Included

• Mounting Brackets

• Heim Joints

• Hardware & Fittings

Compatibility

• 1949–1968 VW Beetle (Bug, Fusca)

• 1949–1968 VW Karmann Ghia

• Kit cars and replicas with swing axle suspension

• Also fits dune buggies, 1973–74 Fridolin, and 1965–1979 UK-spec Beetle & Ghia swing axle models

The PRO’s Recommendations

• Remove the body for ease of installation—trust us, it’s significantly easier. While possible with a pit or lift, body-off installation ensures proper fitment and welding access.

• Welding is required. We recommend a certified welder using a 220-amp machine for proper penetration. (TIG or stick is acceptable; 110-amp welders are not sufficient.)

• If you plan to run heater boxes, slight modification and rerouting of the tubes will be necessary.

• For pre-1958 models with split transaxles or parallel spring plate castings, upgrade to 1959–1965 end castings for compatibility.

Installation Guidance

• If funds allow, have a trained technician or one of our recommended installers complete the job.

• Skilled DIY mechanics with the right tools can install this kit, but professional inspection afterward is advised.

• Estimated installation time: varies depending on equipment access (body-off strongly recommended).

Tech Tip
Proper shock geometry and bracket alignment will ensure maximum performance from your air ride system. Cutting corners on welding or setup will compromise safety and ride quality.
